ELEMENTRAC ON-p 2
(Please order PC, monitor, balance and consumables (starter-kit, anhydrone, sodium hydroxide, copper II oxide) separately)
Measuring ranges at 1,000 mg sample weight (further measuring range combinations on request)
88200-2201
ON-p 2
1xO
0.04 ppm – 0.04 % O
88200-2202
ON-p 2
2xN
0.04 ppm – 3 % N
88200-2203
ON-p 2
2xO
0.04 ppm – 1 % O
88200-2205
ON-p 2
2xO
0.04 ppm – 1 % O
Required accessories
PC, Monitor, Balance
71015-1000
Computer with Intel Core i5-8400 Processor, 256 GB SSD; 8 GB RAM; Windows 10 operating system; keyboard; mouse
88400-0584
Monitor, TFT (23.8")
88400-0645
Balance (resolution 0.0001 g)
Required consumables / chemicals for first operations
88500-0018
ON-Starter-kit for 500 analyses
(400 graphite crucibles, 50 outer graphite crucibles, 200 inner graphite crucibles, 50 g glass wool, 50 g quartz wool)
90200
Anhydrone (magnesium perchlorate), 454 g
90210
Sodium hydroxide, 500 g
90270
Schuetze reagent, 100 g, for OH-p and ONH-p
90289
Copper II oxide, 100 g, for ON-p and ONH-p
88600-0021
Copper oxide wire (for older ONH 2000 analyzer)
Further options and consumables
Accessories (Hardware)
88200-2400
ONH-p Autoloader (incl. autocleaner and vacuum cleaner)
88200-2401
ONH-p Autocleaner (incl. vacuum cleaner)
88400-0467
Chiller (SMC, 5900 W)
88200-9000
Carrier gas purification furnace, without filling (please order filling and quartz wool separately)
72081
Pressure regulator, 1 piece
Crucibles
88400-0471
Graphite crucibles, 400 pieces (recommended for autoloader operation)
90190
Graphite crucibles, 400 pieces (for copper, brass and steel analysis)
90180
Inner graphite crucibles, 100 pieces (requires outer graphite crucible 90185)
90185
Outer graphite crucibles, 50 pieces
Tips
31360
Graphite tip, 1 piece (for crucibles 90190 and 90185)
Capsules (required for any kind of powder analysis)
90257
Nickel capsules, 3.2 x 7 mm, 100 pieces
90256
Nickel capsules, 4.5 x 10 mm, 250 pieces
88400-0066
Nickel capsules, pressed, 12.5 x 5 mm, 100 pieces
90252
Tin capsules, 5 x 18 mm, 100 pieces
Baskets (required for oxygen and nitrogen determination in refractories)
90250
Nickel baskets, 100 pieces, 1 g each
88600-0012
Nickel baskets, high purity (low oxygen), 100 pieces, 1 g each
Fluxes (required for some applications)
90251
Tin pellets, 454 g (for determination of hydrogen in titanium)
90800
Graphite, 50 g (improves oxygen determination)
90258
Nickel accelerator, 100 g (for analysis of high amount of refractories)
Chemicals (fillings for glass and quartz tubes)
88600-0028
Eltrasorb, 500g (black coloured sodium hydroxide)
90200
Anhydrone (magnesium perchlorate), 454 g
90210
Sodium hydroxide, 500 g
90289
Copper II oxide, 100 g, for ON-p and ONH-p
90426-1001
Filling for carrier gas purification furnace (suitable for one filling, ONH series)
90330
Quartz wool, 50 g
90331
Glass wool, 454 g
90332
Glass wool, 50 g
92610
Tube of high vacuum grease, 35 g
ELEMENTRAC - additional tools
All ELEMENTRAC analyzers are equipped with a set of neccessary tools
The following list provide part numbers for replacement of worn tools and some new tools to improve handling.
Spatulas and tweezers
88400-0476
Micro spatula, 1 piece, XS size
23110
Spatula, 1 piece, M size
23111
Spatula, 1 piece, L size
88400-0475
Set with 6 spatula and 1 tweezers, for multiple weighing procedures
88400-0229
Tweezers (160 mm), curved, 1 piece, for transporting pins and baskets
88400-0472
Tweezers (145 mm), straight, 1 piece, for removing samples out of the ONH-p furnace
88400-0213
Tongs for crucibles, 1 piece, for putting crucibles on the electrode tip
Tools for storage, transporting and weighing
88400-0477
Weighing boat, 1 piece, for weighing and usage of granulates
36121
Quartz boat, 74x22x10 mm, 1 piece, for weighing pins
Tools for cleaning and maintenance
27000-8007
O-ring set ONH-p (furnace)
27000-8008
Maintenance kit ONH-p
27000-8009
O-ring set ONH-p
71010
Brush, 16 mm, 1 piece, for cleaning balance from dust
88400-0500
Telescope mirror, 1 piece, for inspection of upper electrode of ONH-p/ONH-2000
88400-0473
Powder funnel (plastics), 1 piece, for easy filling of chemical tubes
88400-0489
Rubber plug 14x20x24 mm, 1 piece, for sealing small glass tubes like 88400-0006
88600-0027
Sodium hydroxide, Anhydrone filter tube
71032
Composite brush, 1 piece, for cleaning upper electrode of ONH-p furnace
71035
Cleaning brush / furnace brush, 1 piece, for cleaning sample inlet of ONH furnaces
71031
Metal brush, 1 piece, for cleaning graphite tip and its holder
88400-0504
Cylinder brush, brass, for intensive cleaning of lower furnace
88400-0501
Micro brush, 1 piece, for cleaning of ONH series furnace outlet tube
61030
Allen key, 3 mm, 1 piece
61040
Allen key, 4 mm, 1 piece
61050
Allen key, 5 mm, 1 piece
Calibration materials
Calibration materials may show slight variations depending on the current lot.
To see the current certification please visit www.ELTRA.com.
Oxygen and nitrogen in steel, pins
91100-1001
Steel, 100 pins, 1 g each, 25 – 40 ppm N
91100-1002
Steel, 100 pins, 1 g each, 30 – 70 ppm N
91100-1003
Steel, 100 pins, 1 g each, 150 – 250 ppm N
91100-1005
Steel, 100 pins, 1 g each, 300 – 600 ppm N
91100-1007
Steel, 100 pins, 1 g each, 70 – 130 ppm N
91100-1010
Steel, 100 pins, 1 g each, >1000 ppm N
91100-1011
Steel, 100 pins, 1 g each, 600-1000 ppm N
Hydrogen in steel, pins
91400-1001
Steel, 100 pins, 1 g each, 0.5 – 1 ppm H
91400-1002
Steel, 100 pins, 1 g each, 1.5 – 4 ppm H
Steel, balls (H)
91110
Steel, 100 balls, gold plated, 1 g each, >1.9 ppm H
Oxygen in copper, pins
91000-1003
Copper, 100 pins, 1 g each, ~200 ppm O
91000-1004
Copper, 100 pins, 1 g each, ~10 ppm O
Oxygen, nitrogen and hydrogen in titanium, pins
91205-1001
Titanium, 100 pins, 0.1 g each, 10 – 35 ppm H
91205-1002
Titanium, 100 pins, 0.1 g each, 20 – 70 ppm H
91205-1003
Titanium, 100 pins, 0.1 g each, 30 – 90 ppm H
91205-1004
Titanium, 100 pins, 0.1 g each, 60 – 120 ppm H
91205-1005
Titanium, 100 pins, 0.1 g each, 150 – 250 ppm H
91205-1006
Titanium, 100 pins, 0.1 g each, 120 – 150 ppm H
Hydrogen and carbon in titanium, pins (250 mg)
91305-1001
Titanium, 100 pins, 0.25 g each, < 50 ppm H
91305-1002
Titanium, 100 pins, 0.25 g each, 50 -100 ppm H
91305-1003
Titanium, 100 pins, 0.25 g each, > 100 ppm H
Please note: Every analyzer requires PC, monitor, balance and some consumables (crucibles, chemicals) which have to be ordered separately
